New Book (PAPERBACK, KINDLE, PDF, EPUB) !


h20221 cover1a solid 3d house ft82117 34
"Step by Step  Design a House
with  AutoCAD 2021"

Table of Contents

  • 1. - Introduction..

    1.1.1 - About the project House20-221

    2. AutoCAD the Basics

    2.1 - Starting AutoCAD
    2.1.1 - Starting AutoCAD 2021.
    2.2 - The AutoCAD Environment
    2.2.1 - Explore τhe AutoCAD Environment

    2.3 - Create Objects.
    2.3.1 - Draw lines.
    2.3.2 - Dynamic input
    2.3.3 - Draw Arcs and Circles.
    2.3.4 - Draw Polylines.
    2.3.5 - Draw Rectangles.
    2.3.6 - Construction Lines.
    2.3.7 - Draw Spline.

    2.4 - Modify objects.
    2.4.1 - Object Properties.
    2.4.2 - Select Objects.
    2.4.3 - Erase Objects.
    2.4.4 - Cut, Copy, Paste Objects.
    2.4.5 - Move - Rotate objects.
    2.4.6 - Offset Objects.
    2.4.7 - Mirror Objects.
    2.4.8 - Fillet and Chamfer
    2.4.9 - Trim – Extend.
    2.4.10 - Break – Join - Pedit polylines.

    2.5 - Apply Layers. 57
    2.5.1 - Create and delete Layers.
    2.6 - Change the Views.
    2.6.1 - Pan and Zoom
  • 3. Ground floor – Step 1

    3.1 - Start your Project h20221.
    3.1.1 - Project h20221- Basic File Preparation
    3.2 - Ground Floor - Draw the Walls.
    3.2.1 - Ground Floor - Draw Outlines.
    3.2.2 - Type Text
    3.2.3 - Draw the Dimensions.
    3.2.4 - Ground floor - Exterior Walls.
    3.2.5 - Ground floor - Interior walls.

    4. Ground floor – Step 2

    4.1 - Blocks.
    4.1.1 - Introduction to blocks.
    4.1.2 - Create block.
    4.1.3 - Insert a Block.
    4.1.4 - Dynamic Blocks.
    4.1.5 - Create the axisBuble block.
    4.2 - Ground floor - The Openings.
    4.2.1 - Ground floor - Create the Doors.
    4.2.2 - Ground floor - Create the Windows.
    4.3. Ground floor - Stair – Furniture – Spaces.
    4.3.1 - Ground floor - Create the Stair
    4.3.2 - Ground floor - Insert the Furniture.

    5. First floor

    5.1 - First floor – Draw the Walls.
    5.1.1 - First floor - Draw the Outline.
    5.1.2 - First floor – Exterior Walls.
    5.1.3 - First floor – Interior Walls.
    5.2 - First floor – The Openings.
    5.2.1 - First floor - Create the Doors.
    5.2.2 - First floor - Create the Windows.
    5.3 - First floor - Furniture.
    5.3.1 - First floor - Insert the Furniture.
  • 6. Site Area

    6.1.1 - Create the Site Plan

    7. Autocad - 3D Modeling

    7.1 - Isometric 3D Views.
    7.1.1 - Use the ViewCube.
    7.1.2 - Use a Visual Style.
    7.2 - Create Solids.
    7.2.1 - Create Solid Primitives.
    7.2.2 - Create 3D Objects using Polysolids.
    7.3 - Create Solids and Surfaces.
    7.3.1 - Working with UCS..
    7.3.2 - Solids or Surfaces by Extruding.
    7.3.3 - Solids or Surfaces by Sweeping.
    7.3.4 - Solids or Surfaces by Revolving.
    7.3.5 - Solid Editing.

    8. Ground floor - 3D Model

    8.1 - Ground floor - 3D solids
    8.1.1 - Ground floor - The Solid Walls
    8.1.2 - Ground floor - Solid wall holes
    8.1.3 - Ground floor – Solid Opening's Frames
    8.1.4 - Ground floor - Solid Doors - Windows
    8.1.5 - Ground floor – Solid Slab and Roofs
    8.1.6 - Ground floor - Solid Stair

    9. First floor 3D Model

    9.1 - First floor 3D Model
    9.1.1 - First floor - Create the solid Walls
    9.1.2 - First floor - The solid wall holes
    9.1.3 - First floor – Solid Opening's frames
    9.1.4 - First floor - solid Doors and Windows
    9.1.5 - First floor – Solid Roof
    9.1.6 - Create the solid 3d Terrain
    9.1.7 - Solid – 3d house20-221
  • 10. Sections – Elevations.

    10.1 - Create a Section Object
    10.1.1 - Create the Sections
    10.1.2 - Create the Elevations

    11. Layout – Paper Space.

    11.1 - Layouts
    11.1.1 – Ground Floor – Layout – Paper Space
    11.1.2 - Layout-A2 – Title Block
    11.1.3 - First Floor – Paper Space
    11.1.4 – Site Plan – Paper Space
    11.1.5 - Sections – Elevations Paper Space
    11.1.6 - House20-221 - 3D Views - Paper Space.

    12. Extract Data. 282

    12.1.1 - Extract Data from Drawings.

    13. Create the Sheets – Plotting

    13.1 - Create the Sheets
    13.1.1 - Create and Organize a Sheet Set
    13.2 - Plotting
    13.2.1 - Plotting h20221_ground Floor

    14. Drawings. 300

    INDEX
